Unitree G1 Humanoid Arm — Building a Full-Stack Manipulation Pipeline in Python

After validating ideas on the Panda arm, I shifted focus to the Unitree G1, a 7-DOF humanoid manipulator.
My goal: write everything—from inverse kinematics to joint-level control—in pure Python on top of Unitree’s DDS-based SDK, then push cycle‐times low enough for reactive tasks like placing Lego bricks.

1. Inverse Kinematics (7-DOF) with Pinocchio + CasADi

The G1’s extra elbow joint gives useful redundancy but complicates IK. I:

1. Modelled the arm in Pinocchio to obtain fast analytical Jacobians and geometry trees.

2. Formulated IK as a non-linear least-squares problem in CasADi:

   [ \min_{\boldsymbol{q}} \; |\, f(\boldsymbol{q}) - \mathbf{x}_{\text{goal}} |_2^2 ] subject to joint limits, self-collision inequality constraints, and a null-space regularizer that biases solutions toward comfort poses.

3. Solved with Levenberg–Marquardt (damped Newton) plus an adaptive λ that shrinks when the solver is near convergence.
4. Achieved < 2 ms median runtime for typical end-effector targets, fast enough to call IK inside the planner loop.

2. Sampling-Based Motion Planner

I implemented an RRT-Connect-style planner that calls the IK solver at each expansion:

• Tree node: Cartesian pose → joint solution (from IK) → collision check (pinocchio.geometry).
• Extension metric: combined translational, rotational, and joint-space distance with tunable weights.
• Early shortcutting: a first-pass smoothing that removes way-points already linearly reachable in collision-free space.
• Planning rate: ≈ 60 Hz on a single core, yielding 100–300 way-points for a 0.5 m reach maneuver.

3. Trajectory Generation & Optimization

Raw way-points are fed into a two-step pipeline:

1. Cubic-Spline Interpolator — produces joint trajectories with continuous velocity/acceleration.
2. Time-Optimal Parameterization (TOPP) — scales the spline to respect joint velocity ( \dot q_{\max} ) and acceleration ( \ddot q_{\max} ) limits.
   • Added an energy-minimizing mode that lengthens segments with low torques to reduce heat during long horizon tasks.

Result: trajectories that track within 0.1 rad/s and 0.3 rad/s² of hardware limits while staying smooth.

4. Real-Time Controller

• Joint-space PID at 1 kHz, gravity terms computed from the Pinocchio model and refreshed every control tick.
• Trajectory blending: a quintic blend window that lets new splines splice into the active motion without abrupt torque jumps.
• Safety layer: soft-torque limit, velocity clamping, and an instant hold mode triggered by a watchdog if no new command is heard within 50 ms.

Dual-Arm Policy Training with LeRobot

I’m also training an action policy for the dual-arm Unitree G1 using the LeRobot pipeline: synchronized camera streams feed a vision encoder, joint states and gripper signals form the proprioceptive branch, and the policy is optimized with behavior cloning plus action smoothing to keep impedance-friendly torques. I gathered demonstrations with a teleoperation pipeline and trained both ACT and diffusion policies for everyday tasks—toast bread, block stacking, snack picking, and similar manipulation—while using domain randomization on lighting and hand-held objects so the network transfers from staged demos to real assembly motions without brittle heuristics.

5. System Integration

Current Achievements

• Sub-millimetre accuracy in peg-in-hole and pick-and-place trials.
• 35 % faster cycle-time than Unitree’s stock planner by avoiding blocking IK calls.
• Modular architecture—IK, planner, generator, and controller can be swapped or tuned independently.

Next Milestone — Autonomous Lego Stacking

Vision: use the stack to pick identical Lego bricks and place them precisely atop one another until a tower forms.

Planned steps:

1. RGB-D Perception: point-cloud segmentation to localize the top brick surface.
2. Grasp Planning: sampling antipodal grips with friction cones checked in real time.
3. Visual Servoing: fine motion within 2 cm using end-effector camera feedback.
4. Adaptive Compliance: impedance control overlay to absorb tiny alignment errors while stacking.

Completion of this task will demonstrate dexterous, repeatable assembly using a fully Pythonic control stack on a commercial humanoid platform.
